titanium plate gr2 titanium sheet astm b265 titanium alloy plate
gr5
| Item Name | GR5 GR7 Ti Plates and Sheets Titanium Alloy Titanium Foil |
| Application | Metallurgy, electronics, petroleum, aerospace Industry, Medical,
Surgical plant, Aerospace, Chemical industry Electronic industry
Mechanical engineering |
| Type | GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6,
TC4, TC6, TC11, TC17, TC18 |
| Standard | ASTM B265, AMS4911, AMS4911H, ASTM F136, ASTM F67 GB/T3621-2007 |
| Specification | Hot Rolling: Length 1000-4000mm,Width 400-3000mm,Thickness 4.1-60mm |
| Cold Rolling :Length 1000-3000mm,Width 400-1500mm,Thickness
0.3-3.0mm |
| Certificate | ISO 9001:2008 |
| Supply Ability | 10 Tons per Month |
| Delivery | Within 5~35 days |
| Grade | Grade 1: Pure Titanium, relatively low strength and high ductility. |
| Grade 2: The pure titanium most used. The best combination of
strength, weldability. |
| Grade 3: High strength Titanium, used for Matrix-plates in shell
and tube heat exchangers. |
| Grade 5: The most manufactured titanium alloy. Exceedingly high
strength. high heat resistance. |
| Grade 7: Superior corrosion resistance in reducing and oxidizing
environments. |
| Grade 9: Very high strength and corrosion resistance. |
| Grade 12: Better heat resistance than pure Titanium. Applications
as for Grade 7 and Grade 11. |
| Grade 23: Titanium-6Aluminum- 4Vanadium ELI. Alloy for surgical
implant application. |
| Grades | C max | O max | H max | Fe max | Al | V |
| Grade1 | 0.08 | 0.18 | 0.015 | 0.20 | / | / |
| Grade2 | 0.08 | 0.25 | 0.015 | 0.30 | / | / |
| Grade5 | 0.08 | 0.20 | 0.015 | 0.40 | 5.50~ 6.75 | 3.50~ 4.50 |
| Grade 12 | 0.08 | 0.25 | 0.015 | 0.30 | / | / |
ASTM B265 Commonly used grades Mechanical Properties (%):
| Grades | Yield Point Mpa (N/mm2) | Tensile Strength Mpa (N/mm2) | Elongation% min |
| Grade1 | 138~ 310 | 242 | 24 |
| Grade2 | 276~ 448 | 345 | 20 |
| Grade5 | 828 | 897 | 10 |
| Grade 12 | 345 | 483 | 18 |
Size:
Thickness:5~100mm, Width:1200~2500mm, length:3000~10000mm
Appliation:Used in: aerospace, military advisor, industrial processes,
automotive, agri-food, medicine, etc.
Unalloyed Titanium grades:
Grade 1,Grade 2,Grade 3,Grade 7,Grade 11 (CP Ti-0.15Pd),Grade
16,Grade 17,Grade 26,Grade 27
Titanium Based Alloys grades:
Grade 5(Ti-6Al-4V),Grade 9 ( Ti 3Al-2.5V),Grade 12
(Ti-0.3-Mo-0.8Ni),Grade 19 (Ti Beta C),Grade 23 (Ti 6Al-4V
ELI),Grade 28
Grades of supply:Gr1 ,Gr2 ,Gr5,Gr12
ASTM B265 Commonly used grades Chemical Composition:
ASTM B265 titanium and titanium alloy sheet
ASTM B265 covers annealed titanium and titanium alloy strip, sheet, and
plate. ASTM B265 Ti and Ti-based alloy plates are widely used in the
equipment for high-temperature environment, including aircraft
equipment, petroleum and petrochemical, biomaterial, ocean and
chemical industry, for example: blade, storage tank, target, tube
and heat-exchanger equipment.
Usually we provide a quality inspection report with the goods,
which shows the chemical composition and physical properties
